NIMO MATRIX is a useful tool for measuring batch measurement of IOLs in the process of production.  It is capable of automatically measuring all kinds of refactive IOLs with max. measurement speed of 300 lense per hour.  With such device, it can dramtically boost production output.

Features:

Automated system for high volume lOL production with 300 IOLs per hour

Integrated with power, MTF, dimension and thickness
Real time power and MTF value

Flexible lens tray

Custom made tray size up to 121 lenses per tray

Accurate dry measurement with Non-paraxial model Eye.

Function：

4in1 measurement

Power Measurement

NIMO MATRIX can accurately evaluate optics performance of IOLs by measurment data like wavefront power map, power profile and sphere, cylinder and toric axis etc.   These information are of utmost importance for quality control by IOL producers

MTF

NIMO TR0815 provides comprehensive analysis on imaging quality through Through Focus Curve MTF in dedicated model eye

Dimension Control

With the NIMO Matrix, you can perform precise dimensional analyse of IOLs. The system automatically recognizes critical dimensions and offers customizable measurement points based on customer specifications, ensuring thorough dimensional analysis in IOL production.

Thickness Measurement

The NIMO Matrix provides unique thickness measurement capabilities for IOLs. It uses state-of-the-art technology to measure thickness at multiple points, ensuring comprehensive and reliable thickness profiles essential for quality control.
